PVC Insulated Galvanized Iron Wire Connector, Screw Type
- Material: Polyvinyl Chloride (PVC)
- Finish: PVC Spray Coating
- Features & Benefits:
- PVC Insulated
- UL94V-2 Standard, 600V
- 100pcs/pack
| Series no. | Product ID | Size | Box / Carton | Note |
|---|---|---|---|---|
| 6030103-45-380 | MCT-P1GY | L=15.2 mm, W=8.6 mm, Wire: 0.3-2.0 mm², 22-14 AWG | 100 | Gray |
| 6030103-45-385 | MCT-P2BE | L=17.6 mm, W=9.8 mm, Wire: 0.3-2.0 mm², 22-14 AWG | 100 | Blue |
| 6030103-45-390 | MCT-P3RG | L=22.0 mm, W=12.0 mm, Wire: 0.3-2.0 mm², 22-14 AWG | 100 | Orange |
| 6030103-45-395 | MCT-P4YW | L=24.5 mm, W=14.0 mm, Wire: 0.3-5.5 mm², 22-10 AWG | 80 | Yellow |
| 6030103-45-400 | MCT-P6RD | L=26.5 mm, W=16.4 mm, Wire: 0.3-8.0 mm², 22-8 AWG | 60 | Red |
Item List
MCT-P1GY
6030103-45-380
- Size:
- L=15.2 mm, W=8.6 mm, Wire: 0.3-2.0 mm², 22-14 AWG
- Box/Carton: 100
- Note:
- Gray
MCT-P2BE
6030103-45-385
- Size:
- L=17.6 mm, W=9.8 mm, Wire: 0.3-2.0 mm², 22-14 AWG
- Box/Carton: 100
- Note:
- Blue
MCT-P3RG
6030103-45-390
- Size:
- L=22.0 mm, W=12.0 mm, Wire: 0.3-2.0 mm², 22-14 AWG
- Box/Carton: 100
- Note:
- Orange
MCT-P4YW
6030103-45-395
- Size:
- L=24.5 mm, W=14.0 mm, Wire: 0.3-5.5 mm², 22-10 AWG
- Box/Carton: 80
- Note:
- Yellow
MCT-P6RD
6030103-45-400
- Size:
- L=26.5 mm, W=16.4 mm, Wire: 0.3-8.0 mm², 22-8 AWG
- Box/Carton: 60
- Note:
- Red
